Maximize Yields with Efficient Dehumidification

Get Started

Home / All / Dehumidifier / Grow Room Dehumidifier /

960 L/D Industrial Dehumidification Units | Large Room Dehumidifier | Whole Room Dehumidifier | Most Efficient Dehumidifier Manufacturer

Categories	Grow Room Dehumidifier
Brand	East Dehumidifier OEM ODM Manufacturing
Model	SDD-960L
Installation	Ceiling / Wall Mounted
Dehumidifying Type	Refrigeration
Refrigeration Technology	Compressor
Compressor Type	Rotary
Refrigerant	R410a
Cooling Capacity	32.8 Kw
Brand Name	Ease Dehumidifier OEM ODM Manufacturing
Location	Zhejiang, China
Condition	Brand New
FOB port	Shanghai or Ningbo
Terms of Payment	Western Union, MoneyGram, T/T, Paypal
Download DOC
Update Time	Apr 19,2024

Contact Now

Favorites

Detail Information

EAST SDD Serise Dehumidifiers

EAST SDD serise Grow Room Dehumidifiers are designed for cultivation, ware house, green house, basement, swimming pool with over head installation. They utilize world-famous compressor, big heat exchanger and centrifugal fan to achieve maximum dehumidifying efficiency and performance. Not only to save the energy consumption, but also to save owners’ investment cost.

Different dehumidification capacity will match different cultivation size. The largest model SDD-960L can meet dehumidification 2020 pints/day (960L/D） at environment 86℉ RH80%. It is widely used for controlling humidity while cultivating cash crops in North America.

Thickened frame metal body is designed for long life installation on ceiling. Saving each floor space for cultivation. Duct kits can be connected on both inlet and outlet.

The accurate humidity controller is already fixed with comprehensive logic circuit. Plants have different humidity requirements with different growth periods. Setting different humidity requirements at different growth periods will maximuize fruitful performance. Owners do not need additional cost to buy controllers again. On the other hand, the third-party controller system can be connected to SDD OEM models if requested in advance.

The optional filters are available for SDD series. Normal filters, medium efficiency filters or high efficiency filters can be chosen for different branding requirements.

EAST dehumidifier manufacturer is open for all world branding buyer to OEM and ODM. Private controller pannel, own logo print, extra function combination, whole production supervision are all available.

Large Room Dehumidifier

FEATURES

Firm frame metal plate body

Clear design and crafts

Long life centrifugal motor

Parameter SDD-960L

Cooling Capacity	110,000 BTU	32.8KW
Water Removal Capacity @30℃, RH80%, 24hrs	2020 Pints	960L
Supply Voltage	380/480V	380/480V
Rated Power	13 Kw	13 Kw
Rated Amps	30 A	30 A
Air Volume @ 0.0" ,CFM	6470	11000m³/h
Static Pressure	100~150 Pa	100~150 Pa
Working Temperature	41℉~100℉	5℃~38℃
Humidity Range (RH)	40%~95%	40%~95%
Net Dimensions	59" x 59.5" x 31.5"	1500x1510x800mm
Packed Dimesions	63" x 63.5" x 39.5"	1680X1590X980mm
Net Weight	826 Lbs	375Kg
Gross Weight	892 Lbs	385Kg
Air Inlet Flange Size	48.6" x 25.8"	1234x654mm
Air Outlet Flange Size	43.5" x 25.8"	1234x654mm
Noise	≤70dB	≤70dB
Applying Area	10,000~13,000 Sqft	1000-1200㎡

SDD-960L Manuals Download

The standard manuals in English version are provided by EAST manufacturer. You can add your own logo or share your requirement to supplement the manuals and any other instructions.

The specifications can be also provided as well as logo printing, name plate making.

Buyers' own manuals or instructions are also welcomed.

The whole production process can be supervised by videos or photos or formal inspection report.

Production order tracking system makes your business easier.

Application

Plant Grow humidity control

Suitable humidity is essential for the plants

During the raining season

To safe guard your goods in dry condition.

Principle of dehumidifier

The priciple of air circulation.

The wet air will be drawn into the machine and passed through the heat exchanger. So the moisture in the air will be condensed into water on the condenser and dry air will be released out of the dehumidifier.

The principle of refrigerant.

High pressure refrigerant liquid enters into the evaporator after throttling by capillary. The refrigerant is evaporated as low temperature and low pressure gas by absorbing thermal from air after heat exchange. The low temperature low pressure refrigerant gas is inhaled into the compressor, after compressor compressing, the gas become high temperature high pressure refrigerant gas and get into the condenser. Then the refrigerant gas get into the condenser, after heat dissipation, the refrigerant gas become high pressure refrigerant liquid. Above is a complete cycle of refrigerating after repeating.

Packaging And Shipping

Packaging And Shipping

Wood packing is a must for dehumidifiers international shipping. To port or to door, get flexible, reliable and affordable shipping solutions that fit your business.

*Fixing with screw on plywood for stable transportation.

* Wrapped with poly to prevent scratching.

*Reserved forklift holes at bottom of carton.

* FOB, CIF, DDP intercoms are welcomed.

After-Sales Guarantee

We provide 12 months warranty for whole unit. If any problem due to our quality within 12 month, please send photo or video to us, we will send the broken parts to you free.

We provide 36 months warranty for the compressor.

The single serise number of each machine can be kept in EAST system, so that we can trace the production source.

We will provide paid parts service after warranty period.

The VIP price of spare parts will be provided for EAST distributors and members.
